Customized Disc Stack Separator Bowl Centrifuge
Customized self-cleaning disc stack separator centrifuge from Huading Separator for factory use, operating at 4000-10000 rpm with centrifugal force exceeding 10,000 g.
Technical Specifications
| Specification |
Details |
| Drive |
Gear / Belt |
| Bowl Speed |
4000 - 10000 rpm |
| Centrifugal Force |
> 10,000 g |
| Bowl Volume |
8 - 300 L |
| Bowl Weight |
50 - 15000 Kg |
| Solids Holding Space |
2 - 50 L |
| Inlet Pressure |
0 - 0.1 Mpa |
| Liquid Outlet Pressure |
0.2 - 0.6 Mpa |
| Starting Time |
5 - 30 mins |
| Stopping Time (no brakes) |
> 40 mins |
Company Overview
Huading Separator has over 60 years of tradition and is the leading manufacturer in mechanical separating technology in China. Our developments serve diverse industries including beverage, dairy, oils and fats processing, chemicals, , biotechnology, starch technology, marine engineering, energy, oil fields, and environmental technology. We develop and build customized centrifuges and complete process lines.
Compliance Standards
- JB/T 8103 standards - Chinese national standard of disc centrifuge
- 2006/42/EC (Machinery)
- 2014/35/EU (Low Voltage)
- 2014/30/EU (Electromagnetic Compatibility)
- Quality management system of ISO9001-2000
Centrifugal Separation Technology
The disc stack separator separates solids and one or two liquid phases from each other in one single continuous process using extremely high centrifugal forces. Denser solids are forced outward against the rotating bowl wall, while less dense liquid phases form concentric inner layers. The interface position between liquid phases can be adjusted for maximum separation efficiency. The disc stack configuration provides additional surface settling area, dramatically speeding up the separation process.
2-Phase Separation Process
Process Flow: 1 Feed → 2 Discharge → 3 Inlet tube → 4 Disc stack → 5 Solids holding space → 6 Centripetal pump chamber → 7 Centripetal pump
Separation occurs inside a rotating bowl where feed is introduced via a stationary inlet pipe. The liquid phase moves through the disc stack to the center and is pumped out, while solids collect in the periphery and are discharged intermittently through a hydraulic system.
3-Phase Separation Process
Components: 1 Inlet tube → 2 Central bore → 3 Distributor → 4 Distributor bore → 5 Rising channels → 6 Light phase centripetal pump → 7 Heavy phase centripetal pump
The suspension enters the separator bowl through a feeding pipe into the disc stack. Heavy phase and sludge move toward the bowl periphery while light phase flows toward the center. Solids collect in the sludge space and discharge intermittently via hydraulic system.
Self-Cleaning Types
Self-cleaning disc stack centrifuges are divided into two main types: Purifiers for separating solids and two liquid phases, and Clarifiers for separating solids and one liquid phase.
Why Choose Huading Separator
Our Advantages
60+ Years
Experience developing and manufacturing disc stack centrifuges
40,000+
Installations in more than 50 countries since 1954
100+
Centrifuge models to satisfy diverse customer demands
Global
References from worldwide food and pharmaceutical manufacturers
Certifications
All our products pass inspection standards including CE and ISO with 100% quality assurance.
Manufacturing Process
Packaging & Shipping
Package
Standard export carton packing
Delivery Time
30-90 days after confirming order. Detailed delivery date determined according to production season and order quantity.
